Shallow mount subwoofers exist for one reason: they fit where full depth subs cannot. A standard 12 inch sub needs 6 to 7 inches of mounting depth, plus the box behind it. Shallow mount 12 inch subs drop that to around 3.5 to 4.5 inches, which is the difference between fitting under a truck seat and not fitting at all. This guide covers the real specs for shallow mount 12 inch subs plus the 8 and 10 inch sizes, including mounting depth, air space, and what you give up to gain that space.
What Makes a Subwoofer Shallow
A shallow mount subwoofer uses a shorter motor structure, a shallower basket, and often a smaller surround to reduce overall depth. The tradeoff is usually in excursion and power handling. A full depth sub can move a lot of air with a long throw motor. A shallow sub has less room to move, so it needs a stiffer suspension and more cone area to make up for it.
That does not mean shallow subs are weak. Modern shallow designs like the Sundown Audio SML series use high excursion motors and stiff cones to get real output from a 3.5 inch deep package. The SML 12 handles 500 watts RMS with a mounting depth around 3.5 inches, which is genuinely impressive for the class. The key is matching the sub to a box with the right air space, because shallow subs are just as sensitive to enclosure volume as full depth subs.
Mounting Depth: The Number That Decides Everything
Before you buy any shallow sub, measure the actual mounting depth available in your vehicle. That means the distance from the mounting surface to whatever is behind it: the floor, the seat frame, the trunk floor, or the rear deck.
Here are the real numbers for the common sizes:
- 8 inch shallow subs: mounting depth around 2.5 to 3.5 inches, ideal for under seat boxes and small kick panels. The Sundown SML 8 runs 300 watts RMS and fits in enclosures as small as 0.3 to 0.5 cubic feet.
- 10 inch shallow subs: mounting depth around 3 to 4 inches, the most popular size for under seat installs in trucks. The SML 10 handles 500 watts RMS in roughly 0.5 to 0.8 cubic feet.
- 12 inch shallow subs: mounting depth around 3.5 to 4.5 inches, for behind the seat truck boxes and shallow trunk enclosures. The SML 12 takes 500 watts RMS in 0.8 to 1.2 cubic feet.
Add the box wall thickness to the sub’s mounting depth when you check fitment. A 3/4 inch MDF wall plus a 3.5 inch sub is 4.25 inches of total depth, and that is what has to fit under the seat.
Air Space Requirements for Shallow Subs
Shallow subs generally want smaller boxes than their full depth cousins, which is convenient because the spaces they go in are small. But smaller does not mean zero. A shallow sub in a box that is too small sounds peaky and loses low end. A shallow sub in a box that is too big loses control and can bottom out.
Use the sub’s spec sheet as the target. For a 12 inch shallow sub, 0.8 to 1.2 cubic feet sealed is typical, with ported options around 1.25 to 1.5 cubic feet tuned to 32 to 35 Hz. For a 10 inch shallow sub, 0.5 to 0.8 cubic feet sealed. For an 8 inch shallow sub, 0.3 to 0.5 cubic feet sealed. These are net volumes, so subtract the sub’s displacement and any port volume from the gross box size.
Sealed vs Ported for Shallow Mounts
Sealed is the default for shallow subs, and for good reason. The small air space works with the stiff suspension to keep the sub controlled, and sealed boxes are easier to build thin. A sealed box for a shallow 12 can be as shallow as 4 to 5 inches total, which is what makes under seat installs possible.
Ported shallow boxes exist, but they are harder to get right. The port needs length to tune low, and a shallow box does not have the depth for a long port. Slot ports along the back wall or side firing ports can work, but the net volume and tuning have to match the sub. If you want ported output from a shallow sub, buy a box that is specifically designed and tuned for that sub, not a generic shallow ported box.
Under Seat and Behind Seat Installations
The two classic shallow sub installs are under the seat and behind the seat.
Under seat: common in trucks and SUVs where the rear seat bottom has 4 to 6 inches of clearance. A down firing or forward firing shallow box under the seat keeps the cargo area free. Measure the seat clearance with the seat in its normal position, and remember that seat heaters, brackets, and carpet all eat into that space.
Behind the seat: common in extended cab and crew cab trucks. The space behind the rear seat is often 5 to 7 inches deep, which fits a shallow sub in a thin box. Behind the seat boxes are usually vehicle specific because the seat angle and cab shape vary by truck.
In both cases, the box is doing as much work as the sub. A thin box with proper bracing and the right net volume will outperform a thicker box with the wrong volume. Check out our shallow subwoofer boxes and enclosures for options sized to these installs.
What You Give Up With a Shallow Sub
Be honest about the tradeoffs. A shallow 12 will not out-loud a full depth 12 in a big ported box. The excursion limit is real, and the smaller motor means less thermal headroom. If you have the space for a full depth sub, run a full depth sub.
But if your vehicle has no space, a shallow sub is not a compromise, it is the only option. A good shallow sub in a properly sized box will still hit hard enough to be felt, and it will do it without giving up your trunk or your back seat. For trucks especially, a pair of shallow 10s or 12s under the seat is a legit daily setup.
Measure your mounting depth first, then match the sub to the space. Pick the size that fits, give it the air space it wants, and use a box built for shallow subs. The Sundown SML series covers the 8, 10, and 12 inch sizes with real power handling and shallow depth, and they are built to take daily abuse.
Ready to fill that tight space with bass? Check out the Sundown Audio SML shallow mount subwoofers in 8, 10, and 12 inch sizes, and pair them with a shallow box that fits your truck or car.
Your Shallow Sub Questions
Do shallow subs sound as good as full size subs?
A good shallow sub gets close in daily driving, but it will not match a full size sub on raw output. The shorter motor limits excursion and thermal headroom, so the deepest notes and max loudness take a hit. In a properly sized box at normal listening levels, most people are happy with the trade.
How much mounting depth do shallow subs need?
Most shallow subs need under 4 inches of mounting depth. Shallow 8s run about 2.5 to 3.5 inches, 10s about 3 to 4 inches, and 12s about 3.5 to 4.5 inches. Add the box wall thickness to the sub depth when you measure your space.
What air space do shallow 12s need?
A shallow 12 usually wants 0.8 to 1.2 cubic feet sealed, or about 1.25 to 1.5 cubic feet ported. Always follow the sub maker’s net air space spec, and subtract the sub’s displacement from the gross box volume.
Are shallow subs good for trucks?
Yes, trucks are the most common home for shallow subs. They fit under the rear seat or behind it without taking cargo space. A pair of shallow 10s or 12s in a proper truck box is a proven daily setup.
